Beschreibung
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don’t worry, you’ll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
Mit dem Kaius 01 Gravel Competition Frame Kit ist Ihr Traumrad nur noch ein paar Schlüsselumdrehungen entfernt.
Der Kaius 01 wird mit BMCs High-Tech-Carbon-Verbundtechnologie hergestellt und stellt den ultimativen Gravel-Rennrahmen dar. Seine für den Rennsport optimierte Geometrie findet die perfekte Balance zwischen Steifigkeit, Leichtigkeit und Komfort und sorgt so für überragende Traktion, Stabilität und Effizienz beim Bergauffahren. Die fortschrittliche Carbon-Konstruktion, das Aerocore-Design und die ICS-Kabelintegration sorgen für eine außergewöhnliche Leistung und ein elegantes aerodynamisches Profil.
Die + Produkte:
- Hochwertiger Kaius 01 Carbon-Rahmen: ACE+ Technologie, Aerocore Design, Tuned Compliance Concept Race.
- Hoch elegantes aerodynmisches Profil
Details:
| Rahmen | Carbon: Kaius 01 Premium Carbon with Aerocore Design, ICS Technology, Stealth Cable Routing, Integrated Aerocore Bottle Cages, Stealth Dropout Design, TCC Race Compliance Level, PF86 Bottom Bracket, Flat Mount Disc, 12×142 mm Thru-Axle, Tire clearance: 44 mm (Measured Width) |
| Gabel | Carbon: Kaius 01 Premium Carbon, ICS Technology, Stealth Cable Routing, TCC Race Compliance Level, Stealth Dropout Design, Flat Mount Disc, 12×100 mm Thru-Axle, 50 mm Offset (Size 47-51), 45 mm Offset (Size 54-61) |
| Sattelstütze | Kaius 01 Premium Carbon D-Shaped Seatpost, 15 mm Offset, D-Fender Compatible |
| Gewicht | 1.8 kg in 54 mit allen Zubehörteilen |
| Maximales Gewicht | 120 kg: Das maximale Systemgewicht umfasst das Fahrrad, den Fahrer und die Ausrüstung |
| Farben | Iron Grey / Black |
Geometrien:
| Rahmengröße (cm) | 47 | 51 | 54 | 56 | 58 | 61 |
| Sattelrohr (mm) | 428 | 452 | 468 | 493 | 513 | 533 |
| Oberes Rohr (mm) | 546 | 559 | 569 | 579 | 592 | 604 |
| Länge der Basis (mm) | 420 | 420 | 420 | 420 | 420 | 420 |
| Lenkhülse (mm) | 85 | 106 | 123 | 144 | 170 | 196 |
| Winkel der Lenkung (°) | 71 | 71 | 72 | 72 | 72 | 72 |
| Winkel Sattelrohr (°) | 73 | 73 | 73 | 73 | 73 | 73 |
| Radstand (mm) | 1003 | 1017 | 1015 | 1026 | 1039 | 1051 |
| Stack (mm) | 510 | 530 | 550 | 570 | 595 | 620 |
| Reichweite (mm) | 390 | 397 | 401 | 405 | 410 | 414 |
| Länge des Vorbaus (mm) | 90 | 100 | 100 | 110 | 110 | 120 |
| Offset Gabel (mm) | 50 | 50 | 45 | 45 | 45 | 45 |
| Länge der Kurbeln (mm) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
